| General Specifications |
| General | - Built-in Web Server
- 802.11b wireless or 10/100Mbps network access
|
| Web Access Requirements | Any Java-Enabled or ActiveX compatible Web Browser. i.e. current versions of Microsoft Internet Explorer or Netscape Navigator |
| Remote Management Software Requirements | Microsoft Windows XP, 2000, Me, 98SE or 98 |
| Video | - 1/3” CMOS Digital VGA Sensor
- 24-bit RGB color
- Resolution: 640x480, 320x240 or 160x120
- 5 Level User Selectable JPEG Compression Rate
- Frame Rate: 1, 5, 7, 15, 20 or Auto (actual performance depends on resolution, compression rate and network performance)
- File size and network bandwidth depends on actual image content, lightness/darkness of content, frame rate, compression level, resolution. Higher compression and low frame rate results in lower bandwidth requirements, while low compression and high frame rates result in higher network bandwidth and higher image quality.
|
| Exposure | - Gain Control: Automatic or Manual
- White Balance: Automatic or Manual
- Brightness Control: Slide bar or display 1-128
- Exposure: Automatic or Manual
- Contrast Control: Slide bar
- Hue Control: Slide bar
- Shutter: 1/60 ~ 1/15000 sec
- Minimum Illumination: 2.5lux@f1.4, 3000K color
- Warning: Never aim the camera directly at the sun or at extreme light sources. Doing so may cause unrecoverable damage to the CMOS sensor.
|
| Warranty | Limited 1-Year Warranty |
| Lens | - Replaceable standard C/CS mount
- Focus: 20cm ~ infinity
- Manual Focus
- Aperture: F 1.8
- Focal Length: 6.0 mm
|
| System Settings Main | - Camera Name & Location
- IP Address: Static or Dynamic
- Default Gateway Address
- DNS Address
- Manager ID (username)
- Manager Password
- Recover Default Values
- Wireless Network Name (ESSID)
- Wireless Channel
- Wireless Encryption Key
- Open Second Port
|
| Date/Time | - Synchronize with time server
- Set Manually
|
| Trigger | - On/Off
- Send e-mail with image attachment
- SMTP server address
- Sender e-mail address
- Receiver e-mail address
- Sending Interval (time between each send)
- Sending Time (number of times an e-mail will be sent)
|
| Protocol Support | HTTP, TCP/IP, UDP, RARP, PING, ARP, DHCP, BootP, PPPoE |
| Network Interface | - 802.3/802.3u NWAY Autosensing 10/100Mbps (RJ-45 Jack)
- Wireless 802.11b Wi-Fi compatible
|
| Firmware Updates | Via Web Interface or Remote Management Software |
| Remote Management Software | - Remotely manage and control unlimited number of DCS-1000W Internet Cameras
- Microsoft Windows XP, 2000, Me, 98SE and 98 compatible
- View 16, 9, 4 or 1 Camera on one screen
- Supports all management functions provided in web interface
- Record streaming video to hard drive in AVI format
- Motion detection to trigger automatic recording
|
| Hardware | - Power Supply: DC 5V/2.4A
- Power Requirements: 6.5Watt (1300mA X 5V)
- User Selectable Network Switch: LAN/LAN&WAN/WAN
- Indoor Use Only. Outdoor Use Requires Protective Housing.
- Operating temperature: 5° ~ 50°C
- Storage temperature: -25° ~ 50°C
- Humidity: 5% ~ 95% non-condensing
- Size: 6.5 in length x 3.5 in width x 2.25 in height
|
| I/O Connector | - Used to connect external triggers (i.e. motion detection)
- Four I/O Ports, 2 x Input, 2 x Output
- I/O Status: Normally On
- 8-Pins Total
- Maximum Current: 100mA
- Output Voltage: DC 5V
|
| LED Indicator | - Power & Link
- Selectable LED Control: Normal, Off, Dummy
|
| EMI & Safety | - FCC Class A, CE, VCCI
- For Industrial Use Only
|
| Accessories Included | - 2 x 802.11b Wireless Antenna
- CAT5 Fast Ethernet Cable
- Stand with multi-angle connectors
- CD with Remote Management and ActiveX Software
- AC Power Adapter
|
| Wireless Specifications |
| Data Rate Mbps/channel | - 11Mbps* : CCK
- 5.5Mbps : CCK
- 2Mbps : DQPSK
- 1Mbps : DBSK
|
| Range** | - Indoor - per cell approximately 114 to 328 feet
- Outdoor - per cell approximately 328 to 984 feet
|
| Encryption | 64-bit, 128-bit or OFF |
| Transmit Power | - Nominal Temp. Range: 17 dBm
- Extended Temp. Range: 14 dBm min.
- Transmit Power, 2.7v to 3v: 14 dBm min.
|
| Receive Sensitivity | Nominal Temp Range: - 1 Mbps 10-5 BER @ -90 dBm, minimum
- 5.5 Mbps 10-5 BER @ -87 dBm, minimum
- 11 Mbps 10-5 BER @ -84 dBm, minimum
Extended Temp Range: - 1 Mbps 10-5 BER @ -84 dBm, minimum
- 5.5 Mbps 10-5 BER @ -81 dBm, minimum
- 11 Mbps 10-5 BER @ - 78 dBm, minimum
|
| Network Architecture | - Supports Ad-Hoc Mode (Peer-to-Peer without Access Point) or Infrastructure Mode (Communications to wired networks via Access Points with Roaming)
- Compliant with IEEE 802.11b Standards
|
| Antenna | - Internal patch antenna supporting diversity
- Mobility: Seamless roaming across cell boundaries within access point range
|
| Frequency Range | 2.4 - 2.4835 GHz, Direct Sequence Spread
Spectrum (DSSS) |
| Operating Channels | - 1-11 United States (FCC)
- 1-11 Canada (DOC)
- 1-14 Japan (MKK)
- 1-13 Europe (Except Spain and France) (ETSI)
|
